Marca | msi |
Modelo | Z270I GAMING PRO CARBON AC (911-7A66-001) |
Plataforma | - Mini-ITX (17.0 cm x 17.0 cm) |
Chipset | - Intel® Z270 Chipset |
CPU Soportados | - Soporta 6th/ 7th Gen Intel® Core™ i3/i5/i7, Intel® Pentium® y Celeron® procesadores para Socket LGA1151 |
Memoria | - 2 x DDR4 memory slots, soporta hasta 32GB - 7th procesadores soporta DDR4 3800(OC)/ 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400/ 2133 MHz* - 6th procesadores soporta DDR4 3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400(OC)/ 2133 MHz* - Dual channel memory architecture - Soporta non-ECC, un-buffered memory - Soporta Intel® Extreme Memory Profile (XMP) |
Slots Expansión | - 1 x PCIe 3.0 x16 slot |
Gráficos | - 1 x HDMI™ 4096x2160@30Hz (7th CPU), 4096x2160@24Hz (6th CPU), 2560x1600@60Hz - 1 x DisplayPort, 4096X2304@24Hz, 3840X2160@60Hz,1920X1200@60Hz |
Puertos E/S, Conectores | Internos - 1 x 24-pin ATX main power - 1 x 8-pin ATX 12V power - 4 x SATA 6Gb/s - 1 x USB 3.1 Gen1 - 1 x USB 2.0 - 1 x 4-pin CPU fan - 2 x 4-pin system fan - 1 x Front panel audio - 2 x Front panel - 1 x RGB LED - 1 x TPM module - 1 x Chassis Intrusion - 1 x Clear CMOS jumper Externos - 1 x PS/2 Teclado y ratón combo- 2 x USB 2.0 - 1 x DisplayPort - 1 x HDMI™ - 1 x USB 3.1 Gen2 Type-A - 1 x USB 3.1 Gen2 Type-C - 1 x LAN (RJ45) - 2 x USB 3.1 Gen1 Type-A - 1 x Clear CMOS button - 2 x Antenna - 1 x Optical S/PDIF out - 5 x OFC audio jacks |
Otras Características | Almacenamiento - 4 x SATA 6Gb/s ports - 1 x M.2 slot (Key M) - Soporta hasta PCIe 3.0 x4 y SATA 6Gb/s - Soporta 2242/ 2260 /2280 storage devices - Intel® Optane™ Memory Ready - Soporta Intel® Smart Response Technology RAID - Soporta RAID 0, RAID 1, RAID 5 y RAID 10 para SATA storage devices Red - 1 x Intel® I219-V Gigabit LAN controller WLAN & Bluetooth - Intel® Dual Band Wireless-AC 8265 module - Soporta Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) hasta 867 Mbps speed. - Soporta Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2 Audio - Realtek® ALC1220 Codec - 7.1-Channel High Definition Audio - Soporta S/PDIF output Puertos USB - 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) - 4 agueros de montaje- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) - 4 x USB 3.1 Gen1 (SuperSpeed USB) - 4 x USB 2.0 (High-speed USB) Montaje |
Fecha Revisión | 12-01-2017 por MSB |
